Page 58
6-4 Insert and Remove the PCMK Card
Publication 1784-UM519C-EN-P - September 2006
If the computer is configured properly, your sound/speaker is enabled, and you
installed the PCMK card successfully, you hear multiple tones when you insert a
card or boot the computer. If you have two PCMCIA cards, there are 2 sets of tones,
one for each card.
Remove the PCMK Card
On most computers, you press the release button and remove the card from the
slot. If this is not applicable to your computer, follow the instructions specified in
its user manual.
You hear multiple tones for each card that you remove, if your system is configured
properly. These tones indicate the card is now disabled.
IMPORTANT
When you install the PCMK card for the first time, please refer
to Chapter 2, “Pre-Installation Procedures”, for information on
how to determine which procedures you need to follow to
successfully configure the PCMK card.
IMPORTANT
You should stop any software communicating with the card
before removing the PC card. If you do not do this, the stray
processes may halt the system’s performance.
19874
