7-10 Choose and Connect a PCMK Cable
Publication 1784-UM519C-EN-P - September 2006
1784-PCM5/B
9-pin D-shell connector
19868-M
From a PLC-5 Classic or PLC-5/250
processor over a DH+ link
To a PLC-5 Classic or PLC-5/
250 processor
PLC-2 or Mini-PLC-2
family processor
1785-KA3
1771-CN
-CO or CR
1784-PCM5/B
PCMK card
30377-M
A 1784-CP7 adapter ships with the cable.
