1-4 About the PCMK/B Card
Publication 1784-UM519C-EN-P - September 2006
Enhancements to the 1784-PCMK/ B Card
The 1784-PCMK/B card contains new enhancements that were not contained in the
1784-PCMK/A card. The PCMK/B card:
• is a 16-bit card.
• connects with a new series of cables using locking connectors.
• will work with newer notebook computers that use PCI bus technology.
• has new updated drivers.
• can be used in conjunction with the PCMK/A card.
Dual PCMK cards are not supported on all operating systems. Refer to
specific operating system chapters for details.
• contains DH+ support at 230 Kbps.
• contains remote I/O scanner capabilities.
IMPORTANT
The PCMK/B card will not connect with the Series A cables.
Please verify that you are using the correct Series B cables when
connecting to the PCMK/ B card.
