Rockwell Automation 1784-PCMK PCMK Communication Card Installation Manual User Manual
Page 60
7-2 Choose and Connect a PCMK Cable
Publication 1784-UM519C-EN-P - September 2006
If you connect to Allen-Bradley
You need
(3)
(3)
All cables contain captive hardware to support the use of positive-locking connections.
PLC-2 Family Processors
(Not supported with cardbus sockets)
PCM2/B Cable Assembly
(cat. no. 1784-PCM2/B)
SLC 5/01 Processors
SLC 5/02 Processors
SLC 5/03 Processors
1747-AIC link coupler for DH485
Other DH485 devices with an RJ45 jack
PCM4/B Cable Assembly
(cat.no. 1784-PCM4/B)
PLC-3 Family Processors
(1)
PLC-5 Family Processors
PLC-5/250 Classic Processors
(1)
Connection is made via DH+ through 1775-S5, SR5
PCM5/B Cable Assembly
(cat. no. 1784-PCM5/B)
SLC 5/04 Processors and PLC-5 Enhanced Processors
ControlNet PLC-5 Family Processors
(2)
Other DH+ devices
ControlLogix 1756-DHRIO Module
(2)
Connection can be made with a PCM5/B cable using an 8-pin mini-DIN connector
PCM6/B Cable Assembly
(cat. no. 1784-PCM6/B)
or
1784-PCM5/B cable with CP7 adapter
Remote I/O Network
(For demo only)
PCMS/A Cable Assembly
(cat. no. 1784-PCMS/A)
