Publication 1784-UM519C-EN-P - September 2006
Appendix
A
Specifications
PCMK Communications Card - 1784-PCMK
Attribute: Value:
Form-factor PCMCIA Type II form-factor network adapter card
Compliant to PCMCIA PC card standard - February 1995
Compliant to PCMCIA Card and Socket Services Standard, Version 2.1
Wiring Category (1)
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation
Wiring and Grounding Guidelines, publication 1770-4.1.
3 - on communications ports
Enclosure None (open-style)
Environmental Specifications
Attribute: Value:
Card Power 160 mA @ 5 VDC
Power Dissipation 0.8 W
Heat Dissipation 2.73 BTU/hr
Conducted RF Immunity IEC 61000-4-6:
10V rms with 1 kHz sine-wave 80%AM from 150 kHz…30 MHz
EFT/B Immunity IEC 61000-4-4:
±1 kV at 5 kHz on communications ports
Emissions CISPR 11:
Group 1, Class A
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0…55 °C (32…131 °F)
Radiated RF Immunity IEC 61000-4-3:
10V/m with 1 kHz sine-wave 80%AM from 30…2000 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100%AM at 1890 MHz
1V/m with 1 kHz sine-wave 80%AM from 2000…2700 MHz
Shock, Nonoperating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
50 g
Shock, Operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
30 g
