Page 23
Install the RSIPCMK Driver for the Windows 95/98 Operating Systems 3-3
Publication 1784-UM519C-EN-P - September 2006
Install the Driver
Perform these steps after you insert the PCMK card into a PCMCIA slot in your
computer. Refer to Chapter 6, Insert and Remove the PCMK Card, for further
information. After you insert the PCMK card, the system will detect the hardware
and begin to build the driver information needed to run the hardware.
1. Obtain the driver from the RSLinx software CD or the Rockwell Automation
Website at http://support.rockwellautomation.com.
Because the driver has not been loaded, you see this dialog:
