Publication 1784-UM519C-EN-P - September 2006
Chapter
2
Pre-installation Procedures
What’s in This Chapter?
Read this chapter to prepare to install your PCMK card.
Verify Your Package Contents
Be certain that you have receive the appropriate items, based on the catalog
number used when ordering, and the list below before you discard any packing
material. If an item is missing or incorrect, contact your local distributor or Rockwell
Automation representative.
Topic
Page
Determine Your Operating System and Software
Determine Your Operating System and Software
Quantity:
Description:
Catalog/Publication
Number:
Notes:
1
PCMK Communication Card
1784-PCMK/B
1
PCM5/B Communication Cable
1784-PCM5/B
Use with 1784-PCMC only
1
PCM6/B Communication Cable
1784-PCM6/B
Use with 1784-PCMCI only
1
PCMK Communication Card User
Manual
1784-UM519
