A-2 Specifications
Publication 1784-UM519C-EN-P - September 2006
Cable Specifications
Vibration IEC 60068-2-6 (Test Fc, Operating):
15 g @ 10…200 Hz
Storage Temperature IEC 60068-2-1 (Test Ab, Unpackaged Non-operating Cold),\
IEC 60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Non-operating Thermal Shock):
-20…65 °C (-4…149 °F)
Surge Transient Immunity IEC 61000-4-5:
±2 kV line-earth (CM) on communications ports
Certifications
Certification (1)
(When product is marked):
Value:
UR UL Recognized Component Industrial Control Equipment. See UL File E65584.
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
CE European Union 89/336/EEC EMC Directive, compliant with:
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and
other certification details.
ATTENTION
Communications cable length must be less than 10 meters
(32.81 feet).
1784-PCM2/B, 1784-PCM4/B, 1784-PCM5/B, 1784-PCM6/B
Total length of cable 3.16 m (10.4 ft) (1)
(1) Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Length from PCMK card connector to pod 17.8 cm (7 in.)
Length from pod to processor 2.8 m (9.2 ft)
Environmental Specifications
Attribute: Value:
