Publication 1784-UM519C-EN-P - September 2006
Chapter
5
Install the 1784-PCMK Driver for
Windows 2000/XP
What’s in This Chapter?
Refer to this chapter to perform the following:
In order to follow the instructions in this chapter, you must:
• have the Windows 2000 or XP operating system loaded.
• have the Windows 2000/XP driver for the PCMK card.
Locate the Windows 2000/XP 1784-PCMK Driver
There are two ways to obtain the 1784-PCMK driver. The driver is located:
• on the RSLinx software version 2.20.107 or later product CD, located in the
PnPDrivers folder
• or visit http://support.rockwellautomation.com, then select PC Cards Utilities
and Downloads.
To: See Page:
Locate the Windows 2000/XP 1784-PCMK Driver 5-1
Download the 1784-PCMK Driver 5-2
Review the 1784-PCMK Hardware Properties 5-6
Navigate to Device Manager 5-10
Eject the 1784-PCMK Card 5-13
Unsafe Removal of Card 5-14
Show the Card Unplug/Eject Icon on the Taskbar 5-16
IMPORTANT
You can have two 1784-PCMK cards configured in the Windows
2000 operating system. If you insert more than one PCMK card
into your PC, only one will be available for use.
