Page 40: Install the driver -2
5-2 Install the 1784-PCMK Driver for Windows 2000/XP
Publication 1784-UM519C-EN-P - September 2006
Download the 1784-PCMK Driver
Follow these instructions to download the 1784-PCMK driver from the Rockwell
Automation Website.
1. Visit our Website at .
2. In the left pane, select PC Cards Utilities and Downloads.
3. Download the 1784-PCMK driver for the Windows 2000 or XP operating
systems, 1784-PCMK_Win2k_XP.zip.
Install the Driver
If you insert multiple PC Cards, you may hear more than one tonal notification per
card. the Windows 2000 operating system detects devices during the power up
process, and adjusts the device resources accordingly. This results in sounding
multiple tones. When the system changes settings, for example removing a card,
the tones will sound again for each change.
1. Insert your 1784-PCMK card. Refer to Chapter 6 “Insert and Remove the
PCMK Card.”
2. After you insert the PCMK card, the system detects the hardware and begins
to build the driver information needed to run the hardware. Because the
driver has not been loaded, You see a new hardware dialog box and the
following message:
