Chapter 4 Manage the Switch via the Device Manager Web Interface
EIP Net
The EIP Net status indicator shows the network status of the switch.
Off
Power to the switch is off or is not properly connected.
Solid green
The switch has an established CIP connection to one or more attached devices.
Blinking green
The switch has an IP address but the switch does not have an established connection to one or more attached
devices.
Blinking red
One or more connections to attached devices have timed out.
Solid red
The switch has detected that its IP address is already in use by another device in the network.
Blinking green and red
The switch is running its power-on self-test (POST).
Setup
The Configuration mode in which the switch is operating.
Off
The switch is configured as a managed switch or the switch is operating as an unmanaged switch.
Blinking green
Switch is in the initial Setup mode or is in the Direct Managed mode, or the initial setup is incomplete.
Pwr A and Pwr B
The Pwr status indicators show the DC power status.
Off
Power to the switch is off or is not properly connected.
Solid green
Power is present.
Solid red
Power to the switch is not present and the power alarm is on.
Table 5 - System-level Status Indicators (continued)
Indicator
Status
Description
Table 6 - Port-level Status Indicators
Indicator
Status
Description
Status
In this mode, the port status indicators show the status of the ports. This is the default mode.
Off
No link
Solid green
No activity on link.
Flashing green
Link activity.
Solid brown
Port has been disabled.
Yellow
An error has disabled the port.
Flashing green and
amber
Faulty link.
Status
Flashing amber
Smartports configuration mismatch on port.
Solid amber
Port is faulty, disabled due to an error, or is in an STP-blocked state.
Duplex
In this mode, the port status indicators show the Duplex mode (Full-duplex or Half-duplex) of the ports.
The 10/100/1000 ports operate only in Full-duplex mode.
Off
No link.
Solid light blue
Port is in Half-duplex mode.
Solid green
Port is in Full-duplex mode.
Speed
In this mode, the port status indicators show the operating speed (10, 100, or 1000 Mbps) of the ports.
Off
No link.
Solid light blue
10 Mbps
Solid green
100 Mbps
Flashing green
1000 Mbps
Smartports
In this mode, each port image shows the applied port role.
