Chapter 2 Getting Started
11. Turn off DC power at the source, disconnect all cables to the switch, and
install the switch in your network.
12. After you complete Express Setup, refresh the personal computer IP
address:
• For a dynamically-assigned IP address, disconnect the personal
computer from the switch, and reconnect the personal computer to the
network. The network DHCP server assigns a new IP address to the
personal computer.
• For a statically-assigned IP address, change it to the previously
configured IP address.
Switch Memory Allocation
The following table provides details on default memory allocation for the
switches.
You can use Switch Database Management (SDM) templates to configure system
resources in the switch to optimize support for specific features, depending on
how the switch is used in the network. You can use a template to provide
maximum system usage for some functions. For example, you can use the default
template to balance resources, and use the access template to obtain maximum
ACL usage. To allocate hardware resources for different usages, the switch SDM
templates prioritize system resources to optimize support for certain features.
The following SDM templates are recommended:
• Default
• Lanbase Routing
You can use the Lanbase Routing template for static and connected routing, or if
you have more than 180 IGMP groups or multicast routes. Other SDM
templates are available, but are not covered in detail.
You can use SDM templates for IP Version 4 (IPv4) to optimize these features.
Feature
Memory Allocation
Default
Lanbase Routing Template
Unicast MAC addresses
8 K
4 K
IPv4 IGMP groups + multicast routes
0.25 K
0.25 K
IPv4 unicast routes
0
0.75
Directly connected IPv4 hosts
0
0.75
Indirect IPv4 routes
0
16
IPv4 policy based routing ACEs
0
0
IPv4/MAC QoS ACEs
0.375 K
0.375 K
IPv4/MAC security ACEs
0.375 K
0.375 K
