Port numbering – Rockwell Automation 1783-Mxxx Stratix 8000 and 8300 Ethernet Managed Switches User Manual User Manual
Page 58

58
Rockwell Automation Publication 1783-UM003I-EN-P - March 2014
Chapter 3 Switch Software Features
Port Numbering
The port ID consists of port type (Gigabit Ethernet for Gigabit ports and Fast
Ethernet for 10/100 Mbps ports), unit number (1, 2, or 3) and port number (1-2
for Gigabits, 1-4 for the 6 port base and 1-8 for all others). Gigabit Ethernet is
abbreviated as Gi and Fast Ethernet as Fa.
The following table shows, as an example, port numbering for the 26-port
Stratix 8000 switch configuration containing the following:
• One 10-port base switch
• One copper expansion module
• One fiber expansion module
Table 1 - Port Numbering
Cat. No.
Unit
Number of Ports
Port Numbering on Switch
Labels
Port Numbering in config.txt
Text File
1783-MS10T
10-port base switch
10 2 Gigabit ports and
eight 10/100 Mbps ports)
Gigabit ports:
1
2
10/100 Mbps ports:
1
2
3
4
5
6
7
8
Gigabit ports:
Gi1/1
Gi1/2
10/100 Mbps ports:
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
1783-MX08T
Copper expansion module
Eight 10/100 Mbps ports
1
2
3
4
5
6
7
8
Fa2/1
Fa2/2
Fa2/3
Fa2/4
Fa2/5
Fa2/6
Fa2/7
Fa2/8
1783-MX08F
Fiber expansion module
Eight 10/100 Mbps ports
1
2
3
4
5
6
7
8
Fa3/1
Fa3/2
Fa3/3
Fa3/4
Fa3/5
Fa3/6
Fa3/7
Fa3/8
