Rockwell Automation 1771-QA Stepper Positioning Assembly User Manual User Manual
Page 86
4–8
Example Programs
Publication 1771-UM002A–EN–P – May 2000
Position
File A Data
File R Data
029
C000
C000
030
0100
0100
MOVE 5
031
0800
0800
032
0100
0100
033
0016
0016
034
0500
0500
035
C000
C000
036
0100
0100
037
0200
0200
MOVE 6
038
0100
0100
039
0017
0017
040
0500
0500
041
C000
C000
042
0100
0100
043
0100
0100
044
0100
0100
MOVE 7
045
0018
0018
046
0500
0500
047
C000
C000
048
0100
0100
049
0050
0050
MOVE 8
050
0100
0100
051
0019
0019
052
0000
0000
053
C000
C000
054
0000
0000
055
0000
0000
056
0100
0100
MOVE 9
057
0019
0019
058
0200
0200
059
C000
C000
060
0200
0200
061
2000
2000
062
0300
0300
MOVE 10
063
0000
0000
064
0000
0000
