Chapter

1

1-1

Introducing The Smart Transmitter Toolkit

This chapter gives you an overview of the Smart Transmitter Toolkit
that you received with your Smart Transmitter Interface (cat. no. 1770-HT1).

The Smart Transmitter Toolkit (STT) is a PLC-5 ladder logic subroutine
utility that saves development time by simplifying the communication
among Allen-Bradley PLC-5 processors, Allen-Bradley Smart Transmitter
Interfaces, and HART-compliant field devices, such as a smart transmitter
or actuator.

✔ The STT subroutine provides a shell that lets you use a PLC processor

to communicate with a HART field device, without having detailed
knowledge of the HART protocol.

✔ The STT subroutine supports the HART commands that are most

commonly used with PLC processors. The STT subroutine does not
support vendor-specific HART commands, such as totalization.

✔ STT focuses on digital data that is associated with the HART protocol.

Use Allen-Bradley Analog I/O modules to acquire 4-20mA analog data.

✔ STT does not include faceplates or operator interface screens. However,

you can configure operator interface software, such as ControlView
software, to display/modify data that is received/sent to the STT
subroutine.

✔ STT supports:

HART Universal Commands 0, 1, and 3
HART Common Practice Commands 35, 38, 43, and 44
Both long- and short-frame addressing
Both point-to-point and multi-drop configurations
Allen-Bradley

PLC-5

processors

Important: Do not view STT as a configuration tool. We assume you take
the appropriate steps to configure and calibrate the HART field device
using either Cornerstone

software or a hand-held terminal.

What's In This Chapter

What's The Smart

Transmitter Toolkit

HART Universal Commands

The functions performed by these commands

are performed by all HART devices.
HART CommonĆpractice Commands

The functions performed by these commands

may not be possible for all HART devices.
HART TransmitterĆspecific Commands

Only one or at most a few HART devices

implement these functions. The functions

performed by these commands allow each

device type to implement their own

commands for special functions, calibration,

and special data handling.
Refer to the product manual for your HART

field device for a list of supported commands.
