1770-6.5.21, b - codes, Codes – Rockwell Automation 1770,D17706.5.21 SMART TRANSMITTER TOOLKI User Manual
Page 51
Appendix
B
B-1
Codes
This appendix contains the codes that you need to use the STT subroutine.
For this list: Integer Word See page:
STT Subroutine Error Codes
31
Smart Transmitter Interface Error Codes
33
HART ProtocolĆCommunication Error Codes
34
HART Command Response Summary Error Codes
35
HART Field Device Error Codes
36
Unit Codes
10, 40
STT Subroutine Error Codes
Integer Word 31
Code
Definition
1
BlockĆtransfer write (BTW) error
2
BlockĆtransfer read (BTR) error
