HART Command Data Table Layouts
Appendix A
A-5
Standard Outputs
Integer Word 30 STT Subroutine Status Word
Word 31 STT Subroutine Error Code
Word 32 Smart Transmitter Interface Status Word
Word 33 Smart Transmitter Interface Error Code
Word 34 HART ProtocolĆCommunication Error Code
Word 35 HART Command Response Summary Error Code
Word 36 HART Field Device Error Code
CommandĆspecific Outputs
Integer Word 40 Primary Variable Unit Code
FloatingĆpoint Word 10 Primary Variable
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 1 9858 269 12807 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 4 0 128 0 0 0 0 0 0 0
N10:40 32 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
This integer word is a commandĆspecific
output that contains the unit code for the
primary variable (see page BĆ5).
These seven integer words are the standard outputs
that contain the status of the communications with
the HART field device (see page 3Ć6).
Data Table Report PLC-5/25 Addr 31 Data Table File F11:0
Address 0 1 2 3 4
F11:0 0 0 0 0 0
F11:5 0 0 0 0 0
F11:10 20.58 0 0 0 0
F11:15 0 0 0 0 0
This floatingĆpoint word is a commandĆspecific
output that contains the primary variable.
HART Command 1
Read Primary Variable
