Rockwell Automation 1770,D17706.5.21 SMART TRANSMITTER TOOLKI User Manual
Page 7
Preface
Using This Manual
iii
We use these conventions in this manual:
In this manual, we show:
Like this:
prompts and messages
Press a function key
literal text that you type
STT_SUB
variable text that you type
filename
keys that you press
F1
screens that you see
Program
Directory
that there is more information about the
topic in another manual
AllenĆBradley Publications
Publication
Publication Number
Smart Transmitter Interface Products (HART Protocol) User Manual
1770Ć6.5.19
PLCĆ5
Programming Software Programming Manual
6200Ć6.4.7
For a list of publications for Allen-Bradley programmable controller
products, see the Automation Group Publication Index, publication SD499.
HART Publications
Publication
Reference Number and Date
HART - Smart Communications
Protocol Specification
Revision 5.1, January 4, 1991
Rosemount, Inc. Document No. D9000047, Revision A
STT is not a licensed software product. It is provided to help you quickly
communicate with HART field devices. Please feel free to use this
software on any and all machines that you have.
Conventions
Related Publications
STT Software License
