Chapter 3
Using The Smart Tranmsitter Toolkit
3-2
Example of Newly Created Integer Data File
Data Table Report PLC–5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 0 0 0 0 0 0 0 0 0 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 0 0 0 0 0 0 0 0 0 0
N10:40 0 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
N10:60 0 0 0 0 0 0 0 0 0 0
N10:70 0 0 0 0 0 0 0 0 0 0
N10:80 0 0 0 0 0 0 0 0 0 0
N10:90 0 0 0 0 0 0 0 0 0 0
N10:100 0 0 0 0 0 0 0 0 0 0
N10:110 0 0 0 0 0 0 0 0 0 0
N10:120 0 0 0 0 0 0 0 0 0 0
N10:130 0 0 0 0 0 0 0 0 0 0
N10:140 0 0 0 0 0 0 0 0 0 0
Integer words 0 through 29 = User Input Area
Integer words 30 through 59 = STT Subroutine Status and Output Area
Integer words 60 through 149 = STT Subroutine Work Area
Example of Newly Created FloatingĆpoint Data File
Data Table Report PLC–5/25 Addr 31 Data Table File F11:0
Address 0 1 2 3 4
F11:0 0 0 0 0 0
F11:5 0 0 0 0 0
F11:10 0 0 0 0 0
F11:15 0 0 0 0 0
FloatingĆpoint words 0 through 9 = User Input Area
FloatingĆpoint words 10 through 19 = STT Subroutine Output Area
