1770-6.5.21, preface, Using this manual – Rockwell Automation 1770,D17706.5.21 SMART TRANSMITTER TOOLKI User Manual
Page 5

Smart Transmitter Toolkit
publication 1770Ć6.5.21
User Manual
Preface
i
Using This Manual
This preface describes how to properly and efficiently use this manual.
It tells you about:
the purpose of this manual
who should use this manual
how to use this manual
terms
abbreviations
conventions
related
publications
Use this manual to install and use the Smart Transmitter Toolkit.
Throughout this manual we refer to this utility as the STT subroutine.
This manual is intended for use by:
persons who install Smart Transmitter Interface products, in connection
with Allen-Bradley PLC
controllers or other intelligent controllers
system integrators who design and establish network systems that
involve plant floor machinery, programmable controllers, HART
field
devices, Smart Transmitter Interface products, and host computers
We assume that you have:
a strong working knowledge of your plant’s process and equipment
a familiarity with personal computers, MS-DOS
or PC-DOS
,
ControlView
, and 6200 programming software
What's In This Preface
Purpose of This Manual
Who Should Use
This Manual
