Save your work (optional) – Rockwell Automation 1770,D17706.5.21 SMART TRANSMITTER TOOLKI User Manual
Page 18
Chapter 2
Installing The Smart Transmitter Toolkit
2-5
A.
Start at the Program Directory and press these keys:
F2
Save
Program
Program
Directory
F2
Save
Restore
You see:
B.
If you want to change the name of the file, enter a new name. If you
don’t enter a new name, the file is saved using the name that you see
on the screen.
C.
To save the file, press
F1
Begin Oper
.
4. Save Your Work (optional)
