HART Command Data Table Layouts
Appendix A
A-11
Standard Outputs
Integer Word 30 STT Subroutine Status Word g
Word 31 STT Subroutine Error Code
Word 32 Smart Transmitter Interface Status Word
Word 33 Smart Transmitter Interface Error Code
Word 34 HART ProtocolĆCommunication Error Code
Word 35 HART Command Response Summary Code
Word 36 HART Field Device Error Code
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 38 9858 269 12807 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 4 0 128 0 0 0 0 0 0 0
N10:40 0 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
These seven integer words are the standard outputs
that contain the status of the communications with
the HART field device (see page 3Ć6).
HART Command 38
Reset Configuration Change Flag
