HART Command Data Table Layouts
Appendix A
A-3
Standard Outputs
Integer Word 30 STT Subroutine Status Word
Word 31 STT Subroutine Error Code
Word 32 Smart Transmitter Interface Status Word
Word 33 Smart Transmitter Interface Error Code
Word 34 HART ProtocolĆCommunication Error Code
Word 35 HART Command Response Summary Error Code
Word 36 HART Field Device Error Code
CommandĆspecific Outputs
Integer Words 40 Ć 42 HART Address of HART field device
This is the HART address that is needed
as an input to the other HART commands.
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 0 0 0 0 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 4 0 128 0 0 0 0 0 0 0
N10:40 9858 269 12807 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
These seven integer words are the standard outputs
that contain the status of the communications with
the HART field device (see page 3Ć6).
Long Frame HART Address
This is the HART address that is needed
as an input to the other HART commands.
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 0 0 0 0 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 4 0 128 0 0 0 0 0 0 0
N10:40 1538 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
These seven integer words are the standard outputs
that contain the status of the communications with
the HART field device (see page 3Ć6).
Short Frame HART Address
HART Command 0
Read HART Address
