Chapter

2

2-1

Installing The Smart Transmitter Toolkit

This chapter provides instructions for installing the Smart Transmitter
Toolkit (STT).

Important: Use 6200 programming software to install the STT subroutine
into your PLC-5 processor. Before you begin, make sure your current
program is loaded.

To install the STT subroutine, you will:

1.

Copy the STT subroutine file to the hard drive.

2.

Create and name a new program file in your PLC-5 processor.

3.

Paste the STT subroutine file into the new program file.

4.

Save your work (optional).

5.

Change the data table defaults (optional)

Important: The STT subroutine uses three fixed word addresses:
N90:0 through N90:2. When you paste the STT subroutine, these
three addresses are created. If these addresses are already in use and
cannot be freed up for the STT Subroutine, you need to change the
data table defaults. If you need to make these changes, do step 5.

The rest of this chapter contains the instructions for completing these steps.

You need this diskette to install the STT subroutine:

Smart Transmitter Toolkit

Allen-Bradley
Software

Disk 1 of 1

This diskette contains these paste files:

STT100.CR5 - the STT subroutine

STT100E1.CR5 - programming example 1

STT100E2.CR5 - programming example 2

STT100E3.CR5 - programming example 3

See chapter 3 for an explanation of the programming

examples.

Since you install the STT subroutine using 6200 programming software,
you may want to obtain a copy of the PLC-5 Programming Software
Programming Manual
, publication 6200-6.4.7.

What's In This Chapter

Before You Begin
