HART Command Data Table Layouts
Appendix A
A-8
Use this command to write new upper and lower primary variable range
values to the data memory of the HART field device. This command then
outputs the actual upper and lower primary range values from the data
memory of the HART field device.
If the write operation was successful, you should see the same values
that you entered.
If the write operation was unsuccessful, you will see the original values
from the data memory of the field device. These values may or may not
be the same as the values that you entered. Check the status and error
codes.
Standard Inputs
Integer
Word 0
I/O Rack Number of 1770ĆHT1
g
Word 1
I/O Group Number of 1770ĆHT1
Word 2
Channel Number of HART field device
Word 3
Polling Address of HART field device
Word 4
Smart Transmitter Interface Command Number 16 (decimal)
Word 5
HART Command Number 35
CommandĆspecific Inputs
Integer
Words 6 Ć 8
HART Address from HART Command 0
g
Word 10
Primary Variable Range Values Unit Code
FloatingĆpoint
Word 0
Primary Variable Upper Range Value
g p
Word 1
Primary Variable Lower Range Value
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 35 9858 269 12807 0
N10:10 32 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 0 0 0 0 0 0 0 0 0 0
N10:40 0 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
This integer word is a commandĆspecific
input and contains the (new) unit code for
the primary variable (see page BĆ5).
These six integer words are the
standard inputs that are required for
each HART command (see page 3Ć3).
This is the HART address that is returned
from HART Command 0 (see page AĆ3).
Data Table Report PLC-5/25 Addr 31 Data Table File F11:0
Address 0 1 2 3 4
F11:0 100.0 0.0 0 0 0
F11:5 0 0 0 0 0
F11:10 0 0 0 0 0
F11:15 0 0 0 0 0
These two floatingĆpoint words are commandĆspecific inputs that
contain the new upper and lower range values for the primary variable.
HART Command 35
Write Primary Variable Range
Values
