Chapter 3

Using The Smart

Transmitter Toolkit

Read chapter 2, then

install the software.

Chapter 2

Installing The Smart

Transmitter Toolkit

Chapter 1

Introducing The Smart Transmitter Toolkit

1-6

We developed the STT Subroutine so that you can easily use a PLC-5
processor to communicate with a HART field device. Here’s how easy it is
to use STT:

1.

Install the STT subroutine into your workstation and PLC-5
processor.

STT

Subroutine

2.

Customize your PLC-5 ladder logic to use the STT subroutine.

a. Allocate data blocks in your PLCĆ5 processor

for each HART field device in your system.

b. Enter a JSR instruction in your ladder logic

program for each 1770ĆHT1 in your system.

When you’ve completed these steps, you’re ready to use the STT
subroutine.

Go to chapter 2 to begin installing the Smart Transmitter Toolkit.

How You Use The STT

Subroutine

What to Do Next
