HART Command Data Table Layouts
Appendix A
A-15
Standard Outputs
Integer Word 30 STT Subroutine Status Word
Word 31 STT Subroutine Error Code
Word 32 Smart Transmitter Interface Status Word
Word 33 Smart Transmitter Interface Error Code
Word 34 HART ProtocolĆCommunication Error Code
Word 35 HART Command Response Summary Code
Word 36 HART Field Device Error Code
CommandĆspecific Outputs
Integer Word 40 Primary Variable Unit Code
Data Table Report PLC-5/25 Addr 31 Data Table File N10:0
Address 0 1 2 3 4 5 6 7 8 9
N10:0 4 6 3 0 16 44 9858 269 12807 0
N10:10 0 0 0 0 0 0 0 0 0 0
N10:20 0 0 0 0 0 0 0 0 0 0
N10:30 4 0 128 0 0 0 0 0 0 0
N10:40 32 0 0 0 0 0 0 0 0 0
N10:50 0 0 0 0 0 0 0 0 0 0
This integer word is the commandĆspecific
output that should contain the unit code that
you entered for the primary variable.
These seven integer words are the standard outputs
that contain the status of the communications with the
HART field device (see page 3Ć6).
HART Command 44
Write Primary Variable Units
