Appendix
B
Adapter Parameters
Appendix B provides information about the adapter parameters.
The adapter parameters are displayed in a Numbered List view order.
Device Parameters
Topic Page
Device Parameters 77
Parameter
No. Name and Description Details
01 [MultiDrv Sel]
Displays the single-drive or multi-drive operating mode based
on Host parameter C169 [MultiDrv Sel] setting. Values: 0 = Disabled
1 = Network Opt
2 = EtherNet/IP
Type: Read Only
02 [DLs From Net Act]
Displays the number of network-to-drive Datalinks that the
drive is using based on the I/O connection opened by the
controller. Minimum: 0
Maximum: 4
Type: Read Only
03 [DLs To Net Act]
Displays the number of drive-to-network Datalinks that the
controller is using based on the I/O connection opened by the
controller. Minimum: 0
Maximum: 4
Type: Read Only
04 [Net Addr Src]
Displays the source from which the adapter’s node address is
taken. This will be either the Node Address switches (see
Setting the Endianness and Node Address Using the DIP
Switches on page 14
) or the value of Device parameter
05 [Net Addr Cfg].
Values: 0 = Switches
1 = Parameters
Type: Read Only
05 [Net Addr Cfg]
Sets the network node address for the adapter when Device
parameter 06 [Net Addr Src] is set to 1 “Parameters”. Default: 126
Minimum: 1
Maximum: 126
Type: Read/Write
Reset Required: Yes
06 [Net Addr Act]
Displays the actual network node address used by the adapter. Minimum: 1
Maximum: 126
Type: Read Only
07 [Net Data Format]
Displays the byte alignment for the network data as selected
with the Byte Swap switch 8 (see
Node Address Switch Settings
on page 15 ).
Values: 0 = Ltl Endian
1 = Big Endian
Type: Read Only
