Getting Started
Chapter 1
Quick Start
This section is provided to help experienced users quickly start using the adapter.
If you are unsure how to complete a step, refer to the referenced chapter.
Step Action
See...
1
Review the safety precautions for the adapter.
Throughout this manual
2
Verify that the PowerFlex drive is properly installed.
PowerFlex 520-Series
Adjustable Frequency AC
Drive User Manual,
publicat
3
Commission the adapter.
Set a unique node address using the switches on the adapter. If desired, you can
disable the switches and use parameter settings instead.
PowerFlex 520-Series
Communication Adapters
Installation Instructions,
publication
4
Install the adapter.
Verify that the PowerFlex drive is not powered. Then, connect the adapter to the drive
using the appropriate interface connector (included with adapter).
5
Connect the adapter to the PROFIBUS network.
Verify that the PROFIBUS network is not powered. Then, connect the adapter to the
network using a PROFIBUS cable.
6
Apply power to the drive and to the network.
The adapter receives power from the drive.
a. Verify that the adapter is installed correctly and then apply power to the drive.
The status indicators should be green. If they flash red, there is a problem.
See
.
b. Configure and verify key drive parameters.
7
Configure the adapter for your application.
Set adapter parameters for the following functions as required by your application:
– Node address
– I/O configuration
– Master-Slave hierarchy
– Fault actions
8
Configure the PROFIBUS Master to communicate with the adapter.
Use controller configuration tools such as Prosoft Configuration Builder software for
PROFIBUS and RSLogix 5000 or Logix Designer software to configure the master on the
PROFIBUS network to recognize the adapter and drive.
Configuring the
PROFIBUS Master
9
Configure the I/O.
Use a controller configuration tool such as RSLogix 5000 or Logix Designer software
that enables you to control the adapter and connected drive using I/O.
