Specifications 5-10
Publication 198-UM002A-EN-P December 2001
➊ These specifications are for reference only. Refer to sensor specification for exact values.
Module Voltage Rating 24V DC
Module Operating Voltage Range 11…25V DC
Module Current Draw w/o Sensor 26 mA @ 24V DC
Input Voltage Rating 24V DC
Input On-State Voltage 10…26V DC
Input On-State Current 3.0 mA @ 10V DC
7.2 mA @ 24V DC
Input Off-State Voltage 0…5V DC
Input Off-State Current < 1.5 mA
Short Circuit Detect Level < 2V DC
Open Circuit Detect Level < 100 µ A
Module Isolation Non-isolated mis-wire protected
Input Filter — Software
Selectable (with two I/O modules) Off to On 1, 2, 4, 8, 16 ms
On to Off 1.3, 2, 4, 8, 16 ms
Input Compatibility IEC 1+
Sensor
Sensor Operating Voltage Typ. 3-wire ➊ 11…25V DC
Typ. 2-wire 18…25V DC
Sensor Current Draw Max. ➊ 100 mA
Environmental
Ambient Temperature Operating –25…+40°C (–4…+104°F)
Storage –40…+85°C (–40…+185°F)
Relative Humidity 0…95% non-condensing
Shock Operating 30 g peak acceleration
Non-Operating 50 g peak acceleration
Operating Vibration 10 g @ 58…2000 Hz
0.060 in. peak-to-peak displacement 2…57 Hz
Per IEC 68-2-6
Approvals
Agency Certification
(when product is marked) cULus Listed
CE marked for all applicable directives
Table 5.7 198-IB2S Specifications (Continued)
