B-4 Motor Starter Operation
Publication 198-UM002A-EN-P December 2001
Instance 150 is the default output (consumed) assembly for Standard Distributed Starters
Standard Distributed Starter Input (Produced) Assemblies
Instance 52 is the required input (produced) assembly defined in the DeviceNet Motor Starter
Profile.
Instance 151 is the default input (produced) assembly for Standard Distributed Starters
Reversing Distributed Starter I/O Assemblies
These assemblies are available when the Motor Starter Type parameter is set to the value 2 =
Reversing Starter.
Reversing Distributed Starter Output (Consumed) Assemblies
Instance 3 is the required output (consumed) assembly defined in the DeviceNet Motor
Starter Profile.
Instance 152 is the default output (consumed) assembly for Standard Distributed Starters
Reversing Distributed Starter Input (Produced) Assemblies
Instance 52 is the required input (produced) assembly defined in the DeviceNet Motor Starter
Profile.
Instance 153 is the default input (produced) assembly for Reversing Distributed Starters
Table B.2 Instance 150 — Default Consumed Standard Distributed Starter
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Output 8
Output 7
Output 6
Output 5
Output 4
Output 3
Output 2
Run
1
Output 16
Output 15
Output 14
Output 13
Output 12
Output 11
Output 10
Output 9
Table B.3 Instance 151 — Default Produced Standard Distributed Starter
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Location 1 Location 0 Status 6
Status 5
Status 4
Status 3
Status 2
Status 1
1
Error 6
Error 5
Error 4
Error 3
Error 2
Error 1
Error 0
Location 2
2
Input 8
Input 7
Input 6
Input 5
Input 4
Input 3
Input 2
Input 1
3
Input 16
Input 15
Input 14
Input 13
Input 12
Input 11
Input 10
Input 9
4
Input 24
Input 23
Input 22
Input 21
Input 20
Input 19
Input 18
Input 17
Table B.4 Instance 152 — Default Consumed Reversing Distributed Starter
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Output 8
Output 7
Output 6
Output 5
Output 4
Output 3
Run Rev
Run Fwd
1
Output 16
Output 15
Output 14
Output 13
Output 12
Output 11
Output 10
Output 9
