A-14 DeviceNet Information
Publication 198-UM002A-EN-P December 2001
Byte-wise Input (Produced) Assemblies
The Byte-wise produced assemblies contain status information in their first few bytes. The
meanings of the status bits are given in the tables below:
Table A.20
Location Bits Description
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0 No Fault
0 0 0 0 0 0 0 1 Module 1
0 0 0 0 0 0 1 0 Module 2
0 0 0 0 0 0 1 1 Module 3
0 0 0 0 0 1 0 0 Module 4
0 0 0 0 0 1 0 1 Module 5
0 0 0 0 0 1 1 0 Module 6
0 0 0 0 0 1 1 1 Module 7
0 0 0 0 1 0 0 0 Module 8
0 0 0 0 1 0 0 1 Module 9
0 0 0 0 1 0 1 0 Module 10
0 0 0 0 1 0 1 1 Module 11
0 0 0 0 1 1 0 0 Module 12
0 0 0 0 1 1 0 1 Module 13
0 0 0 0 1 1 1 0 Module 14
0 0 0 0 1 1 1 1 Module 15
0 0 0 1 0 0 0 0 Module 16
Error Decoding
Error 6 Error 5 Error 4 Error 3 Error 2 Error 1 Error 0 Description
0 0 0 0 0 0 0 No Error
0 0 0 0 0 0 1 Module Added
0 0 0 0 0 1 0 Module Removed
0 0 0 0 0 1 1 Module Different
0 0 0 0 1 0 0 Invalid ID
0 0 0 0 1 0 1 Invalid Module
Configuration
0 0 0 0 1 1 0 Too Many Modules
0 0 0 0 1 1 1 Csum Error Count > 500
0 0 0 1 0 0 0 Unused
0 0 0 1 0 0 1 EEPROM Failure
0 0 0 1 0 1 0 Unable to Power Bus
0 0 0 1 0 1 1 Sensor Voltage Error
0 0 0 1 1 0 0 Over Current
0 0 0 1 1 0 1 Short Term
Over-temperature
0 0 0 1 1 1 0 Long Term
Over-temperature
