DeviceNet Information A-5
Publication 198-UM002A-EN-P December 2001
A single instance (instance 1) of the Identity Object is supported. The following instance
attributes are supported.
➊ The value of the Distributed Starter Type attribute (attribute 63) in the DeviceNet Interface Object (Class code
0xB4) at power up determines the product type, product code and name string that the MDSA reports in
attributes 2, 3 and 7 of the Identity object. Note that the Distributed Starter Type attribute only exists for Cat.
No. 198-DNG units. The values of identity object attributes 2, 3 and 7 are given in the table below.
The following common services are implemented for the Identity Object.
Table A.3
Attribute ID Access
Rule
Name Data Type Value
1 Get Vendor ID UINT 1
2 ➊ Get Device Type UINT 12
3 ➊ Get Product Code UINT 67 for 198-DN
98 for 198-DNG
4 Get Revision
Major Revision
Minor Revision Structure of:
USINT
USINT
4
1
5 Get Status WORD Bit 0 - 0=not owned; 1=owned by master
Bit 2 - 0=Factory Defaulted; 1=Configured
Bit 8 - Minor Recoverable fault
Bit 9 - Minor Unrecoverable fault
Bit 10 - Major Recoverable fault
Bit 11 - Major Unrecoverable fault
6 Get Serial Number UDINT unique number for each device
7 ➊ Get Product Name
String Length
ASCII String Structure of:
USINT
STRING
11
“Modular DSA”
9 Get Configuration
Consistency Value UINT Unique value depending on output of the
parameter checksum algorithm.
Table A.4
Motor
Starter
Type Description Vendor
ID Product
Type
(att #2) Product
Code
(att #3) Name String
0 Not a Standard Starter 1 12 98 Modular DSA
1 190-D Distributed Starter 1 22 1 Bulletin 190-D
2 191-D Reversing Distributed Starter 1 22 2 Bulletin 191-D
3 160-D Inverter Type Distributed Starter 1 22 3 Bulletin 160-D
4 150-D Soft Start Type Distributed Starter 1 22 4 Bulletin 150-D
Table A.5
Service Code Implemented for: Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x05 No Yes Reset
