DeviceNet Information A-33
Publication 198-UM002A-EN-P December 2001
➊ Applies to Cat. No. 198-DNG units
➋ Applies to Cat. No. 198-DN units
➌
➍ Four “Motor Starter Types” can be selected via this attribute: Standard Distributed Starter, Reversing
Distributed Starter, Inverter Type Distributed Starter, and Softstart Distributed Starter. For a complete
description of “Motor Starter Type” operation, refer to Appendix B
38
Get
Module ID Slot 5 USINT
0…17
➌
39
Get
Module ID Slot 6 USINT
0…17
➌
40
Get
Module ID Slot 7 USINT
0…17
➌
41
Get
Module ID Slot 8 USINT
0…17
➌
42
Get
Module ID Slot 9 USINT
0…17
➌
43
Get
Module ID Slot 10 USINT
0…17
➌
44
Get
Module ID Slot 11 USINT
0…17
➌
45
Get
Module ID Slot 12 USINT
0…17
➌
46
Get
Module ID Slot 13 USINT
0…17
➌
47
Get
Module ID Slot 14 USINT
0…17
➌
48
Get
Module ID Slot 15 USINT
0…17
➌
49
Get
Module ID Slot 16 USINT
0…17
➌
50
Get/Set PNB COS Mask
WORD
0…0x00FF
0
Change of state mask for PNBs
1= COS enabled
0= COS disabled
55
Get/Set Prod Assy Word 4 USINT
0…51 ➊
0…60 ➋
5
Defines Word 4 of Assy 120
56
Get/Set Prod Assy Word 5 USINT
0…51 ➊
0…60 ➋
6
Defines Word 5 of Assy 120
57
Get/Set Prod Assy Word 6 USINT
0…51 ➊
0…60 ➋
9
Defines Word 6 of Assy 120
58
Get/Set Prod Assy Word 7 USINT
0…51 ➊
0…60 ➋
10
Defines Word 7 of Assy 120
59
Get/Set Con Assy Word 0 USINT
0…8
5
Defines Word 0 of Assy 121
60
Get/Set Con Assy Word 1 USINT
0…8
6
Defines Word 1 of Assy 121
61
Get/Set Con Assy Word 2 USINT
0…8
7
Defines Word 2 of Assy 121
62
Get/Set Con Assy Word 3 USINT
0…8
8
Defines Word 3 of Assy 121
63 ➍
Get/Set Motor Starter
Type
USINT
0…3
0
See notes below
Table A.62
Attribute
ID
Access
Rule
Name
Data Type Min/Max
Default
Description
0 = No Module
5 = 198-IB4/IB4S
10 = Reserved
15 = Reserved
1 = 198-IB2S
6 = 198-OW1-G3
11 = 198-IB2XOB5S
16 = 198-IA1-G4-9000
2 = 198-IA2XOW1
7 = 198-OW2/OW2S/OW2-G4 12 = 198-OW2S-Q5
17 = 198-IB2S-Q5
3 = 198-IB2XOW1
8 = 198-IB2XOB1
13 = Reserved
18-255 = Invalid
4 = 198-IA2/IA2-G4 9 = Reserved
14 = 198-IB2XOB2S-Q5
