A-28 DeviceNet Information
Publication 198-UM002A-EN-P December 2001
Instances 5 and 6 are the available group 1 or group 3 explicit message connections that are
allocated through the UCMM. The following attributes are supported:
The following services are implemented for the Connection Object.
Discrete Input Point Object
CLASS CODE 0x0008
The following class attributes are supported for the Discrete Input Point Object:
Table A.48 Instances 5 and 6 Attributes
Attribute ID Access Rule Name Data Type Value
1 Get State USINT 0=nonexistant
1=configuring
3=established
4=timed out
2 Get Instance Type USINT 0=Explicit Message
3 Get Transport Class Trigger USINT 0x83 - Server, Transport Class 3
4 Get Produced Connection ID UINT Depends on message group and
Message ID
5 Get Consumed Connection ID UINT Depends on message group and
Message ID
6 Get Initial Comm Characteristics USINT 0x22
7 Get Produced Connection Size UINT 0x61
8 Get Consumed Connection Size UINT 0x61
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get Watchdog Action USINT 01 = auto delete
03 = deferred delete
13 Get Produced Connection Path
Length UINT 0
14 Get Produced Connection Path Empty
15 Get Consumed Connection Path
Length UINT 0
16 Get Consumed Connection Path Empty
Table A.49
Service Code Implemented for: Service Name
Class Instance
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Table A.50
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 0-64
