Instance 103
This input (produced) assembly was included in the Series B MDSA. Its length (in bytes) is
equal to the number of I/O modules on the back-plane plus 4 bytes of status information. It
has the following format:
Instance 105
This is the default input (produced) assembly for the Cat. No. 198-DNG. It was included in
the Series B MDSA as the default produced assembly. It is eight bytes long (6 I/O modules
on an MDSA gland plate, plus 2 bytes of status). It has the following format:
Table A.21 Instance 103 — Modular Input Assembly Instance for
Cat. No. 198-DNG
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Location 1 Location 0 Status 6
Status 5
Status 4
Status 3
Status 2
Status 1
1
Error 6
Error 5
Error 4
Error 3
Error 2
Error 1
Error 0
Location 2
2
Location 7 Location 6 Location 5 Location 4 Location 3 Location 2 Location 1 Location 0
3
Error 7
Error 6
Error 5
Error 4
Error 3
Error 2
Error 1
Error 0
4
Module 1 data
5
Module 2 data
6
Module 3 data
:
:
:
:
n
Module n data
Table A.22 Instance 105 — Default Input Assembly Instance for Cat. No. 198-DNG
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Location 1 Location 0 Status 6
Status 5
Status 4
Status 3
Status 2
Status 1
1
Error 6
Error 5
Error 4
Error 3
Error 2
Error 1
Error 0
Location 2
4
Module 1 data
5
Module 2 data
6
Module 3 data
7
Module 4 data
8
Module 5 data
9
Module 6 data
