5-5 Specifications
Publication 198-UM002A-EN-P December 2001
Connection Capacity
Solid wire 0.13…1.5 mm 2 (24…16 AWG)
Flexible wires
0.13…2.5 mm
2
(24…14 AWG)
Flexible wires with ferrules
0.5…2.5 mm
2
(20…14 AWG)
Plastic collar
1.5 mm
2
(16 AWG)
Wire Type Use 75 C copper wire min.
Tightening Torque 0.5…0.6 Nm (4.4…5.3 lb-in.)
Connector (M12 Male 5-Pin)
M12 Mounting Hole 16 mm (5/8 in.)
M12 Thread M12 x 1 mm
M12 Connector Torque 1.4 Nm (12 lb-in.)
Electrical
DeviceNet Supply Voltage 11.0…25.0V DC
DeviceNet Input Current (no options) 55 mA max.
DeviceNet Input Current Max. 1.8 A
DeviceNet Input Current Surge 15 A for 250 µ S
Environmental
Ambient Temperature Operating –25…+40 ° C (–4…+104 ° F)
Storage –40…+85
°
C (–40…+185
°
F)
Relative Humidity 0…95% (non-condensing)
Shock Operating 30 g peak acceleration
Non-Operating 50 g peak acceleration
Operating Vibration 10 g @ 58…2000 Hz
0.030 in. peak-to-peak displacement 2…57 Hz
Per IEC 68-2-6
DeviceNet Communications
Baud Rates 125, 250, 500 kbps
Distance Max. 500 m (1630 ft) @ 125 kbps
200 m (656 ft) @ 250 kbps
100 m (328 ft) @ 500 kbps
Approvals
Agency Certification cULus Listed
CE Marked for all applicable directives
Table 5.4 DeviceLogix Information
Maximum Function Blocks 48
Table 5.3 198-DN and 198-DNG General Specifications (Continued)
