Publication 0160-5.18 - June 2003
B-12 DeviceNet Information
Class Code 0x28 —
Motor Data Object
Instance 1 Attributes
Common Services
Class Attributes: None Supported Number of Instances: 1
Attribute ID
Access
Rule
Name Data Type Min/Max Units Default Description
6 Get/Set Rated Current UINT 0 to 100.00 0.01 Amps
115% of
Drive Rating Rated Stator Current
(from motor nameplate)
7 Get/Set Rated Voltage UINT 110 to 460 1 Volt Drive Rating
Rated Base Voltage
(from motor nameplate)
9 Get/Set RatedFreq UINT 10 to 240 1 Hz 60 Hz
Rated Electrical Frequency
(from motor nameplate)
15 Get/Set BaseSpeed UINT 200 to 32000 1 RPM
1800
RPM Nominal Speed at Rated Frequency
(from motor nameplate)
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
