Publication 0160-5.18 - June 2003
DeviceNet Information B-9
Class Code 0x0F —
Parameter Object Class Attributes
Number of Instances: 118
Instance 1 through 118 Attributes
➀ Value varies based on parameter instance.
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 118
8 Get Parameter Class Descriptor WORD 0x0B
9 Get Configuration Assembly Instance UINT 190
10 Get Native Language USINT 0 = English
Attribute ID Access Rule Name Data Type Value
1 Set Parameter Value
data type specified in
Descriptor, Data Type and
Data Size
➀
2 Get Link Path Size USINT ➀
3 Get
Link Path
Segment type/port
Segment Address
ARRAY of DeviceNet path
BYTE
path
6
“20 B3 24 01 30 01” ➀
4 Get Descriptor WORD ➀
5 Get Data Type USINT ➀
6 Get Data Size USINT ➀
7 Get Parameter Name String SHORT_STRING ➀
8 Get Units String SHORT_STRING ➀
9 Get Help String SHORT_STRING ➀
10 Get Minimum Value data type ➀
11 Get Maximum Value data type ➀
12 Get Default Value data type ➀
13 Get Scaling Multiplier UINT ➀
14 Get Scaling Divisor UINT ➀
15 Get Scaling Base UINT ➀
16 Get Scaling Offset INT ➀
17 Get Multiplier Link UINT ➀
