Specific instance attributes, continued – Rockwell Automation 825-MDN Smart Motor Manager DeviceNet Communication Card User Manual User Manual
Page 57

Publication 825-UM002A-EN-P - December 2000
A-35
Specific Instance Attributes, Continued
➊ Available with SMM version 3.11 (or higher) / 825-MDN version 6.001 (or higher) product combination only.
Attribute ID
Access
Rule
Name
(param. #)
Data
Type
Min/
Max
Default
Description
131
Get/Set
sp2_t_of (#104)
USINT
0…240
2
Off-delay of auxiliary relay #3
132
Get/Set
dis_fct2 (#107)
BOOL
0…1
0
Disable protection functions from Control Input #2 on/off
133
Get/Set
drs_tr_r (#117)
USINT
0…7
0
Phase reversal trip, relay assignment
134
Get/Set
pas_tr_r (#119)
USINT
0…7
0
Phase loss trip, relay assignment
135
Get/Set
pt_tr_re (#133)
USINT
0…4, 7
0
Pt100 #1…#6 trip, relay assignment
136
Get/Set
pt_al_re (#148)
USINT
1…4, 7
1
Pt100 #1…#6 warning, relay assignment
137
➊
Get
sp_in_st (#20)
UINT
0…3
0
Status of Control inputs #1 and #2; bit 0=Input 1 status,
bit 8=Input 2 status; 0=OFF, 1=ON
138
➊
Get/Set
re2_comm (#225)
BOOL
0…1 0
Aux
#2
relay
ON/OFF
command
139
➊
Get/Set
re3_comm (#226)
BOOL
0…1
0
Aux #3 relay ON/OFF command
140
➊
Get/Set
anout_us (#230)
USINT
0…2
0
Analog output configuration:
0=Thermal utilization (0-100%)
1=PT100max (0-200°C)
2=Motor current (0-200%)
141
➊
Get/Set
rel_remt (#231)
BOOL
0…1
0
Control relays #2 and #3 via DeviceNet
142
Get/Set
Aux2 Pr FltState (#234)
BOOL
0…1
0
Aux relay #2 behavior on a trip condition.
0 = “Go to Value”, 1= “Hold Last State”
143
Get/Set
Aux2 Pr FltValue (#235)
BOOL
0…1
0
Go To Value setting for parameter #234.
0 = OFF, 1= On
144
Get/Set
Aux2 Dn FltState (#236) BOOL
0…1
0
Aux relay #2 behavior on a comm. fault condition. 0 =
“Go to Value”, 1= “Hold Last State”
145
Get/Set
Aux2 Dn FltValue (#237) BOOL
0…1
0
Go To Value setting for parameter #236.
0 = OFF, 1= On
146
Get/Set
Aux2 Dn IdlState (#238) BOOL
0…1
0
Aux relay #2 behavior on a comm. idle condition. 0 = “Go
to Value”, 1= “Hold Last State”
147
Get/Set
Aux2 Dn IdlValue (#239) BOOL
0…1
0
Go To Value setting for parameter #238.
0 = OFF, 1= On
148
Get/Set
Aux3 Pr FltState (#240)
BOOL
0…1
0
Aux relay #3 behavior on a trip condition.
0 = “Go to Value”, 1= “Hold Last State”
149
Get/Set
Aux3 Pr FltValue (#241)
BOOL
0…1
0
Go To Value setting for parameter #240.
0 = OFF, 1= On
150
Get/Set
Aux3 Dn FltState (#242) BOOL
0…1
0
Aux relay #3 behavior on a comm. fault condition. 0 =
“Go to Value”, 1= “Hold Last State”
151
Get/Set
Aux3 Dn FltValue (#243) BOOL
0…1
0
Go To Value setting for parameter #242. 0 = OFF, 1= On
152
Get/Set
Aux3 Dn IdlState (#244) BOOL
0…1
0
Aux relay #3 behavior on a comm. idle condition. 0 = “Go
to Value”, 1= “Hold Last State”
153
Get/Set
Aux3 Dn IdlValue (#245) BOOL
0…1
0
Go To Value setting for parameter #244. 0 = OFF, 1= On
