Publication 825-UM002A-EN-P - December 2000
A-15
Parameters Supported
➊ Values 254 and 255 indicate an error (PT100 short circuit or open circuit).
❷ Available with SMM version 3.11 (or higher) / 825-MDN version 6.001 (or higher) product combination only.
➌ Available with SMM version 2.xx (and lower).
Parameter No.
®=read-only
Parameter
Name
Object
Mapping
Description Data
Type Units Min/Max Default
1 ® I Motor 0x2C-1-5 AvgPhaseCurrent in % of FLC - Average
of 3 Currents INT % FLC 0…1200 0
2 ® Th Utilize 0x2C-1-7 % Thermal Capacity Utilization USINT % 0…100 0
3 ® I Motor L1 0x2C-1-8 PhaseCurrentL1 in % of FLC - Actual
motor phase current L1 INT % FLC 0…1200 0
4 ® I Motor L2 0x2C-1-9 PhaseCurrentL2 in % of FLC - Actual
motor phase current L2 INT % FLC 0…1200 0
5 ® I Motor L3 0x2C-1-10 PhaseCurrentL3 in % of FLC - Actual
motor phase current L3 INT % FLC 0…1200 0
6 ® Time to Trip 0x2C-1-102 Time to trip UINT seconds 0…9999 9999
7 ® Asymmetry 0x2C-1-6 % Phase Imbalance USINT % 0…100 0
8 ® I Earth-H 0x2C-1-103 Ground fault current via Holmgreen
Method in % of actual motor current USINT % 0…100 0
9 ® I Earth-C 0x2C-1-11 Ground fault current via core balance
transformer UINT mA 0…500 0
10 ® T Ambient 0x0F-10-1 Platinum RTD Ambient Temp. Sensor USINT ° C 0…255 ➊ 0
11 ® PT100 #1 0x0F-11-1 Platinum RTD Temp Sensor #1 USINT ° C 0…255 ➊ 0
12 ® PT100 #2 0x0F-12-1 Platinum RTD Temp Sensor #2 USINT ° C 0…255 ➊ 0
13 ® PT100 #3 0x0F-13-1 Platinum RTD Temp Sensor #3 USINT ° C 0…255 ➊ 0
14 ® PT100 #4 0x0F-14-1 Platinum RTD Temp Sensor #4 USINT ° C 0…255 ➊ 0
15 ® PT100 #5 0x0F-15-1 Platinum RTD Temp Sensor #5 USINT ° C 0…255 ➊ 0
16 ® PT100 #6 0x0F-16-1 Platinum RTD Temp Sensor #6 USINT ° C 0…255 ➊ 0
17 ® PT100 max 0x0F-17-1 Platinum RTD Max Temp of all Sensors USINT ° C 0…255 ➊ 0
18 ® Actual Trip 0x2C-1-104 Actual Trip Cause - Bit-string UINT 0…0xFFFF 0
19 ® Actual Warning 0x2C-1-105 Actual Warning Cause - Bit-string UINT 0…0xFFFF 0
20 ® ❷ Control Inputs 0x29-1-137 State of Control Inputs #1, #2 UINT 0…0x101 0
21 ❷ Full Load Curr 0x2C-1-3 TripFLCSet - Overload FLC UDINT 0.01 A 50…200,000 2000
21 ➌ Full Load Curr 0x2C-1-3 TripFLCSet - Overload FLC UINT 0.01 A 50…63,000 2000
22 Locked Rot Curr 0x2C-1-106 Locked Rotor to FLC Current Ratio
(2.5…12.0 times FLC) USINT times 0.1FLC 25…120 60
23 Locked Rot Time 0x2C-1-165 Maximum Locked Rotor Time UINT seconds 1…600 10
24 Thermal Trip Rel 0x29-1-100 Thermal Trip Relay Assignment, 0=main
7=None USINT 0, 7 0
25 Thermal Warning 0x2C-1-107 Thermal Warning, 0=OFF 1=ON BOOL 0…1 0
26 Th Warning Level 0x2C-1-108 Thermal Warning Level USINT % 50…99 75
