Instance 3 Attributes (Group 1 Message Connection)
Attribute
ID
Access
Rule
Name
Data Type
Value
1
Get
State
USINT
0=nonexistant
1=configuring
3=established
4=timed out
2
Get
Instance Type
USINT
0=Explicit Message
3
Get
Transport Class Trigger
USINT
0x83 - Server,
Transport Class 3
4
Get
Produced Connection ID
UINT
0????xxxxxx
xxxxxx=source MAC ID
5
Get
Consumed Connection ID
UINT
0????xxxxxx
xxxxxx=source MAC ID
6
Get
Initial Comm Characteristics
USINT
0x21
7
Get
Produced Connection Size
UINT
0xFF
8
Get
Consumed Connection Size
UINT
0xFF
9
Get/Set
Expected Packet Rate
UINT
Set by Master (2500)
12
Get
Watchdog Action
USINT
01
13
Get
Produced Connection Path
Length
UINT
# of bytes in produced
connection path (00)
14
Get
Produced Connection Path
Empty
15
Get
Consumed Connection Path
Length
UINT
# of bytes in consumed
connection path (00)
16
Get
Consumed Connection Path
Empty
