Parameters Supported, Continued
Parameter
No.
®=read-only
Parameter
Name
Object
Mapping
Description
Data
Type
Units
Min/Max
Default
123
PT100 #2 Trip
0x0F-123-1
PT100 #2 Trip, 0=OFF 1=ON
BOOL
0…1
0
124
#2 Trip Temp
0x0F-124-1
PT100 #2 Trip, Temperature
USINT
°
C 50…200
50
125
PT100 #3 Trip
0xB4-1-19
PT100 #3 Trip, 0=OFF 1=ON
BOOL
0…1
0
126
#3 Trip Temp
0x0F-126-1
PT100 #3 Trip, Temperature
USINT
°
C 50…200
50
127
PT100 #4 Trip
0x0F-127-1
PT100 #4 Trip, 0=OFF 1=ON
BOOL
0…1
0
128
#4 Trip Temp
0x0F-128-1
PT100 #4 Trip, Temperature
USINT
°
C 50…200
50
129
PT100 #5 Trip
0x0F-129-1
PT100 #5 Trip, 0=OFF 1=ON
BOOL
0…1
0
130
#5 Trip Temp
0x0F-130-1
PT100 #5 Trip, Temperature
USINT
°
C 50…200
50
131
PT100 #6 Trip
0x0F-131-1
PT100 #6 Trip, 0=OFF 1=ON
BOOL
0…1
0
132
#6 Trip Temp
0x0F-132-1
PT100 #6 Trip, Temperature
USINT
°
C 50…200
50
133
PT100 #1-6 Relay 0x29-1-135
PT100 #1...#6 Trip, Relay Assignment
USINT
0…4, 7
0
134
PT100 #1-6 Reset 0x0F-134-1
PT100 #1...#6 Trip Reset, 0=Manual
1=Automatic
BOOL
0…1
0
136
#1 Warning
0x0F-136-1
PT100 #1 Warning, 0=Off 1=On
BOOL
0…1
0
137
#1 Warning Temp 0x0F-137-1
PT100 #1 Warning, temperature
USINT
°
C 50…200
50
138
#2 Warning
0x0F-138-1
PT100 #2 Warning, 0=Off 1=On
BOOL
0…1
0
139
#2 Warning Temp 0x0F-139-1
PT100 #2 Warning, temperature
USINT
°
C 50…200
50
140
#3 Warning
0x0F-140-1
PT100 #3 Warning, 0=Off 1=On
BOOL
0…1
0
141
#3 Warning Temp 0x0F-141-1
PT100 #3 Warning, temperature
USINT
°
C 50…200
50
142
#4 Warning
0x0F-142-1
PT100 #4 Warning, 0=Off 1=On
BOOL
0…1
0
143
#4 Warning Temp 0x0F-143-1
PT100 #4 Warning Temperature
USINT
°
C 50…200
50
144
#5 Warning
0x0F-144-1
PT100 #5 Warning, 0=Off 1=On
BOOL
0…1
0
145
#5 Warning Temp 0x0F-145-1
PT100 #5 Warning, temperature
USINT
°
C 50…200
50
146
#6 Warning
0x0F-146-1
PT100 #6 Warning, 0=Off 1=On
BOOL
0…1
0
147
#6 Warning Temp 0x0F-147-1
PT100 #6 Warning, temperature
USINT
°
C 50…200
50
148
#1-6 Warning Rel 0x29-1-136
PT100 #1-#6 Warning Relay 1=alarm
2=Aux #1 3=Aux #2 4=Aux #3
7=None
USINT
1…4, 7
1
150
T amb in Image
0x0F-150-1
PT100 #7 Include Ambient Temperature
in Thermal Image, 0=OFF 1=ON
BOOL
0…1
0
151 ®
Device MAC ID
0x03-1-1
Device MAC ID
USINT
0…63
63
152 ®
Baud Rate
0x03-1-2
Communication Baud Rate 0=125kB
1=250kB 2=500kB
USINT
0…2
0
154
Trip Reset
0x29-1-12
Remote Trip Reset Via Communications
0=No Reset 1=Reset
BOOL
0…1
0
