Rockwell Automation 825-MDN Smart Motor Manager DeviceNet Communication Card User Manual User Manual
Page 32

Publication 825-UM002A-EN-P - December 2000
A-10
Instance 2 Attributes (Predefined Slave Polled I/O Message)
Attribute
ID
Access
Rule
Name
Data
Type
Value
1
Get
State
USINT
0=nonexistant
1=configuring
3=established
4=timed out
2
Get
Instance Type
USINT
1= Poll Message
3
Get
Transport Class Trigger
USINT
0x82 - Server, Transport
Class 2
4
Get
Produced Connection ID
UINT
10xxxxxx100
xxxxxx=node address
5
Get
Consumed Connection ID
UINT
10xxxxxx101
xxxxxx=node address
6
Get
Initial Comm Characteristics
USINT
0x21
7
Get
Produced Connection Size
UINT
0…8 Size of assembly
instance selected
8
Get
Consumed Connection Size
UINT
0…1 Size of assembly
instance selected
9
Get/Set
Expected Packet Rate
UINT
Set by Master (00)
12
Get/Set
Watchdog Action
USINT
0=transition to timed out
1=auto delete
2=auto reset
13
Get
Produced Connection Path
Length
UINT
0…6 depending on path
type
14
Get/Set
Produced Connection Path
Set by Master during
configuration
15
Get
Consumed Connection Path
Length
UINT
0…6 depending on path
type
16
Get/Set
Consumed Connection Path
Set by Master during
configuration
