Publication 825-UM002A-EN-P - December 2000
A-22
Parameters Supported, Continued
Parameter No.
®=read-only
Parameter Name
Object
Mapping
Description
Data
Type
Units
Min/Max
Default
189 ®
Duration Pow Off
0x0F-189-1
Duration of Power Failure, Hours
UINT
Hours
0…255
0
190 ®
Duration Pow Off
0x0F-190-1
Duration of Last Power Failure, Minutes UINT
Minutes
0…59
0
191 ®
I Bef Last Trip
0x0F-191-1
Motor Current Before Last Trip
UINT
%
0…1200
0
192 ®
As Bef Last Trip
0x0F-192-1
Asymmetry Before Last Trip
UINT
%
0…100
0
193 ®
EF H Bef Last Trip
0x0F-193-1
Earth Fault Current Before Last Trip,
Holmgreen
UINT
%
0…100
0
194 ®
Max T Bef L Trip
0x0F-194-1
Maximum Temperature Before Last
Trip, PT100 #1...#6
UINT
°
C 0…200
0
195 ®
Number of Starts
0x0F-195-1
Total Number of Motor Starts
UINT
0…65535
0
196 ®
Number Th Trip
0x0F-196-1
Total Number of Thermal Trips
UINT
0…65535
0
197 ®
Number As Trip
0x0F-197-1
Total Asymmetry Trips
UINT
0…65535
0
198 ®
Number OC Trip
0x0F-198-1
Total Over-Current/Locked Rotor Trips
UINT
0…65535
0
199 ®
Number EF Trip
0x0F-199-1
Total Earth Fault Trips
UINT
0…65535
0
200 ®
Number SC Trip
0x0F-200-1
Total Short Circuit Trips
UINT
0…65535
0
201 ®
Number UL Trip
0x0F-201-1
Total Underload Trips
UINT
0…65535
0
202 ®
Number PTC Trip
0x0F-202-1
Total Over-Temperature Trips
UINT
0…65535
0
203 ®
Number PR Trip
0x0F-203-1
Total Phase Sequence Trips
UINT
0…65535
0
204 ®
Number PL Trip
0x0F-204-1
Total Phase Failure Trips
UINT
0…65535
0
205 ®
Numb PT100 Trip
0x0F-205-1
Total Over-Temperature (PT100) Trips
UINT
0…65535
0
206
Primary CT Used
0x2C-1-162
Primary Current Transformer Used
0=No 1=Yes
BOOL
0…1
0
207
Primary CT Ratio
0x2C-1-163
Primary to Secondary Current Ratio
UINT
1…2000
1
208
Isolation Class
0x2C-1-164
Motor Insulation Class, 0=ClassB
1=ClassE =ClassF
UINT
0…2
0
209 ®
Language
0x0F-0-10
LCD Language Display
USINT
0…4
0
210 ®
EF C Bef Trip
0x0F-210-1
Earth Current before Last Trip
UINT
mA
0…55,000 0
211 ®
Faulted/Trip
0x29-1-10
1=Tripped, 0=Not Tripped
BOOL
0…1
0
212 ®
Warning Present
0x29-1-11
1=Warning Present 0=No Warning
BOOL
0…1
0
213 ®
Fault Code
0x29-1-13
ODVA Starter Profile Fault Code
UINT
0…0xffff
0
214 ®
Warning Code
0x29-1-14
ODVA Starter Profile Warning Code
UINT
0…0xffff
0
215
Output Assembly
0xB4-1-16
Output Assembly instance number
USINT
0, 2, 5
2
216
Input Assembly
0xB4-1-17
Input Assembly instance number
USINT
0,50,51,
100…104
103
