Publication 825-UM002A-EN-P - December 2000
A-27
Instance 6 Attributes
Instance 7 Attributes
Instance 8 Attributes
Instance 9 Attributes
Instance 10 Attributes
Attribute ID Access Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Thermal Prot.”
2
Get
Number of Members UINT
9
3-11
Get
Parameter Numbers
UINT
21,206,207,22,
23,24,25,26,27
Attribute ID
Access
Rule
Name
Data Type
Value
1
Get
Group Name
String
SHORT_STRIN
G
“Asymmetry Prot.”
2
Get
Number of
Members
UINT
7
3-9
Get
Parameter
Numbers
UINT
28,29,30,31,32,33,34
Attribute
ID
Access
Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Overcurrent Pr.”
2
Get
Number of Members
UINT
7
3-9
Get
Parameter Numbers
UINT
35,36,37,38,39,40,41
Attribute
ID
Access
Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Earth-Fault Pr.”
2
Get
Number of Members
UINT
12
3-14
Get
Parameter Numbers
UINT
42,43,44,45,46,47,48,
49,50,51,52,53
Attribute ID
Access
Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Short Circ.Pr.”
2
Get
Number of Members UINT
4
3-6
Get
Parameter Numbers
UINT
54,55,56,57
