Publication 825-UM002A-EN-P - December 2000
A-7
7KH IROORZLQJ WDEOH LQGLFDWHV WKH ,2 $VVHPEO\ 'DWD $WWULEXWH PDSSLQJ IRU
2XWSXW $VVHPEOLHV
Instance104 Data Format (Vendor Specific Input Assembly)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Reserved Reserved Reserved Reserved Reserved Warning Faulted
1 % Thermal Capacity Used, TCU
2 Average 3Ø Current (Low byte)
3 Average 3Ø Current (High byte)
4 Asymmetry
5 Max value of all temperature sensors
6 Earth Current (Low byte)
7 Earth Current (High byte)
Data Name Class Instance Attribute
Name Number Number Name Number
Faulted Control
Supervisor 29
hex
1 Faulted 10
Warning Control
Supervisor 29
hex
1 Warning 11
Reset Fault Control
Supervisor 29
hex
1 ResetFault 12
Average 3Ø Current Overload 2C
hex
1 AvgCurrent 5
Current L1 Overload 2C
hex
1 CurrentL1 8
Current L2 Overload 2C
hex
1 CurrentL2 9
Current L3 Overload 2C
hex
1 CurrentL3 10
% Thermal Capacity
Used Overload 2C
hex
1 % Thermal 7
Earth Current Overload 2C
hex
1 Ground Current 11
Asymmetry Overload 2C
hex
1 % PhImbal 6
Max Value of all
Temperature Sensors Overload 64
hex
1 Pt100max 107
