Parameters supported, continued – Rockwell Automation 825-MDN Smart Motor Manager DeviceNet Communication Card User Manual User Manual
Page 45

Publication 825-UM002A-EN-P - December 2000
A-23
Parameters Supported, Continued
➊ Available with SMM version 3.11 (or higher) / 825-MDN version 6.001 (or higher) product combination only.
Parameter
No.
®=read-only
Parameter Name
Object
Mapping
Description
Data
Type
Units
Min/
Max
Defaul
t
217
Assembly Word 0
0xB4-1-7
Used when Param #216 = 100
USINT
0…214
1
218
Assembly Word 1
0xB4-1-8
Used when Param #216 = 100
USINT
0…214
0
219
Assembly Word 2
0xB4-1-9
Used when Param #216 = 100
USINT
0…214
0
220
Assembly Word 3
0xB4-1-10
Used when Param #216 = 100
USINT
0…214
0
221
®
Hdw. Installed
0x0F-221-1
Option Cards Installed bit-string
bit0 - 825-MST
bit1 - not used
bit2 - 825-MLV
bit3 - 825-MMV
bit4 - 825-MDN (DeviceNet)
WORD
0…31
222
®
Current Convert.
0x0F-222-1
Current Converter bit-string
bit0 - 2.5 A
bit1 - 20 A
bit2 - 180 A
bit3 - 630 A
WORD
1…8
223
Default DN IO
0xB4-1-21
Sets parameters 215…220 to their
factory defaults.
0=no action, 1=reset to defaults
WORD
0…1
0
224
®
➊
TH Bef Last Trip
0x0F-224-1
Thermal Utilization Before Last Trip
UINT
%
0…100
0
225
➊
Aux #2 Cmd
0x29-1-138
Turns Aux #2 relay ON or OFF when
p231 is enabled. 0=OFF, 1=ON, 2=no
comm control
USINT
0…2
0
226
➊
Aux #3 Cmd
0x29-1-139
Turns Aux #3 relay ON or OFF when
p231 is enabled. 0=OFF, 1=ON, 2=no
comm control
USINT
0…2
0
227
➊
2nd Prim CT Used
0x2C-1-168
Second primary CT enable
BOOL
0…1
0
228
➊
2nd Prim CT Rat
0x2C-1-169
Second primary-to-secondary CT ratio
UINT
1…2000 1
229
➊
Core CT Ratio
0x2C-1-170
Core balance CT
primary-to-secondary ratio
UINT
1…2000 100
230
➊
Analog Out Cfg
0x29-1-140
0=Thermal Utilization (0…100%)
1=PT100max (0…200
°
C)
2=Motor current (0…200%)
USINT
0…2
0
231
➊
Aux Relay
Remote
0x29-1-141
Control relays Aux #2 and #3 via
DeviceNet
BOOL
0…1
0
