A-18
Parameters Supported, Continued
Parameter
No.
®=read-only
Parameter Name
Object
Mapping
Description
Data
Type
Units
Min/
Max
Default
77
Max. Start Time
0x2C-1-142
Maximum Starting Time
USINT
seconds
1…240 10
78
Starttime Exceed
0x29-1-118
Starting Time Exceeded, Relay Assignment USINT
0…7
0
79
Rel-con Mn/Wrn
0x29-1-119
Main / Warning Relay Connection.
Bit-string
0=Non-Fail-Safe 1=Fail Safe
WORD
0…195 128
80
Th Trip Reset
0x29-1-143
Thermal Trip Reset, 0=Manual
1=Automatic
BOOL
0…1
0
81
Th Reset Level
0x2C-1-144
Thermal Trip Reset at... % of Thermal
Utilization
USINT
%
10…10
0
50
82
Cool-Const Ratio
0x2C-1-145
Cooling Constant Ratio, Motor OFF / Motor
ON (1.0…5.0)
USINT
0.1
10…50 25
83
PTC Trip
0x0F-83-1
Thermal Protection PTC, 0=OFF 1=ON
BOOL
0…1
0
84
PTC Trip Relay
0x29-1-120
PTC Trip, Relay Assignment
USINT
0…7
0
85
PTC Trip Reset
0x0F-85-1
PTC Trip Reset, 0=Manual, 1=Automatic
BOOL
0…1
0
86
Control Input #1
0x29-1-121
Control Input #1, 0=OFF 1=ON
BOOL
0…1
0
87
Delay Aux Rel #2
0x29-1-122
Time Delay of Auxiliary Relay #2, 0=OFF
1=ON
BOOL
0…1
0
88
On Delay Aux #2
0x29-1-123
On Delay of Auxiliary Relay #2
USINT
seconds
0…240 1
89
Off Delay Aux #2
0x29-1-124
Off Delay of Auxiliary Relay #2
USINT
seconds
0…240 2
90
Speed Switch
0x29-1-125
Speed Switch / Stop Indicator, 0=OFF 1=ON BOOL
0…1
0
91 ®
Sp Switch Relay
0x29-1-126
Speed Switch / Stop Indicator, Trip Relay
Assignment (is the same as no. 38)
USINT
0…7
0
92
Disable Prot #1
0x29-1-127
Disable Protective Functions, 0=OFF
1=ON
BOOL
0…1
0
93
As Prot #1
0x2C-1-146
Asymmetry Protection, 0=Not Disable
1=Disable
BOOL
0…1
0
94
OC Prot #1
0x2C-1-147
Overcurrent / Locked-Rotor Protection,
0=Not Disable 1=Disable
BOOL
0…1
0
95
EF Prot #1
0x2C-1-148
Earth Fault Protection, 0=Not Disable
1=Disable
BOOL
0…1
0
96
SC Prot #1
0x2C-1-149
Short Circuit Protection, 0=Not Disable
1=Disable
BOOL
0…1
0
97
UL Prot #1
0x2C-1-150
Underload Protection, 0=Not Disable
1=Disable
BOOL
0…1
0
98
St Inhib Prot #1
0x2C-1-151
Limiting the Starts Per Hour, 0=Not Disable
1=Disable
BOOL
0…1
0
99
PTC Prot #1
0x0F-99-1
PTC Protection, 0=Not Disable 1=Disable
BOOL
0…1
0
