Instance 1 attributes, Instance 2 attributes, Instance 3 attributes – Rockwell Automation 825-MDN Smart Motor Manager DeviceNet Communication Card User Manual User Manual
Page 48: Instance 4 attributes, Instance 5 attributes

Publication 825-UM002A-EN-P - December 2000
A-26
Instance 1 Attributes
Instance 2 Attributes
Instance 3 Attributes
Instance 4 Attributes
Instance 5 Attributes
Attribute ID
Access
Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Main Values”
2
Get
Number of Members
UINT
4
3-6
Get
Parameter Numbers
UINT
1, 3, 4, 5
Attribute ID Access Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Prot. Values”
2
Get
Number of Members
UINT
5
3-7
Get
Parameter Numbers
UINT
2, 6, 7, 8, 9
Attribute ID Access Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Sensor
Values”
2
Get
Number of Members
UINT
8
3-10
Get
Parameter Numbers
UINT
10,11,12,13,14
,15,16,17
Attribute ID Access Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Faults”
2
Get
Number of Members
UINT
7
3-9
Get
Parameter Numbers
UINT
18,180,181,182,
183,184,213
Attribute ID Access Rule
Name
Data Type
Value
1
Get
Group Name String
SHORT_STRING
“Warnings”
2
Get
Number of Members
UINT
2
3-4
Get
Parameter Numbers
UINT
19, 214
